Dimensional drawings
R2009 Control unit
247 mm (9.72”)
224 mm (8.81”)
219 mm (8.62”)
111 mm (4.37”)
135 mm (5.31”)
67 mm
(2.63”)
280 mm (11.02”)
260 mm (10.23”)
R3016 Control unit
+
_
455 mm (17.91”)
477 mm (18.77”)
505 mm (19.88”)
280 mm (11.02”)
120 mm (4.72”)
67 mm
(2.63”)
19
'LVFRYHURWKHUPDULQHHOHFWURQLFVQDYLJDWLRQRQRXUZHEVLWH
