Simrad R2009 User Manual

Alert text Description
Alert
type
SPD Long. Axis FAIL Speed longitudinal axis data failure W
SPD Tran. Axis FAIL Speed transversal axis data failure W
STW FAIL Speed Through Water failure W
TGT in GZ Tracked target # within the vessel's guard zone W
Train TGT CPA FAIL Training target CPA out of range W
Train TGT TCPA FAIL Training target TCPA out of range W
TRIG FAIL Trigger failure W
TT Capacity 95%
Tracked target processing/displaying is about to be
exceeded
C
TT Capacity Full Tracked target capacity exceeded. W
TT Lost: # Tracked target # is lost W
UTC Data FAIL UTC data failure W
VID FAIL Radar video failure W
Operating modes fallback
The following table shows possible failure categories, and which operations that are allowed
or not allowed when the failure occurs.
Failure Possible alert Fallback
arrangement
Function Inhibited
Heading failure GYRO FAIL
Automatic
switch to relative
motion head-up
mode
• AIS
• Acquiring/Tracking Radar Targets
Speed through
water failure
Speed LOG FAIL
STW FAIL
Possible to set
Manual speed
• AIS
Course and
speed over
ground failure
Speed LOG FAIL
SOG FAIL
EPFS speed FAIL
Automatic
switch to relative
motion, relative
vectors and sea
stabilization
• True vectors
Position input
failure
POSN Invalid
POSN
Unavailable
• AIS
Radar video
input failure
RADAR FAIL
Possible to
display target
information
based on AIS
data
AIS input failure AIS FAIL
• AIS
The alert system | R2009/R3016 User manual
65
