Power
Supply voltage
12-24 V DC
Power consumption
R2009
11 W
R3016
20 W
Compass safe distance
Safe distance to the
standard magnetic
compass
Safe distance to the
steering magnetic
compass
R2009 Control unit
0.34 m
0.25 m
R3016 Control unit
0.65 m
0.43 m
Technical specifications
| R2009/R3016 User manual
73
71
73
Table of Contents
Default Chapter
5
Table of Contents
5
Introduction
8
R2009 and R3016 Radar Control Units
8
O2000 Controller
8
System Diagrams
8
The User Interface
10
Front Panel and Keys
10
Main Panel
11
PPI Symbols
12
Picture Freeze Indicator
12
Softkeys
13
The Menu System
13
Measurements Units
14
Radar Palettes
14
On-Screen Keyboard
15
Screen Capture
15
Basic Operation
16
Turning the System on and off
16
Adjusting Display Brightness
16
Selecting Radar Source
16
Switching between Transmit and Standby Mode
16
Adjusting the Radar Range
16
Using the Cursor
16
Target Tracking
17
Selecting Speed Source and Stabilization Mode
17
Adjusting the Radar Image
18
Gain
18
Rain Anti-Clutter
18
Sea Anti-Clutter
18
Tune
19
Radar View Options
20
Target Trails and Past Position
20
Radar Orientation
20
Radar Motion Mode
20
Offsetting the PPI Center
21
Vectors
21
Cursor Bearings
22
Applying Default Control Settings
22
Target Tracking
23
Managing Targets
23
Defining Dangerous Vessels
23
Radar Targets
23
AIS Targets
26
Displaying Target Information
27
Navigation Tools
29
Guard Zones
29
EBL/VRM Markers
29
Measuring Range and Bearing
31
Advanced Radar Options
33
Use Modes
33
Noise Rejection
34
Installation
35
Viewing Angle
36
U-Bracket Mounting
37
Wiring
38
Ethernet Connector
39
External Alarm
40
NMEA 2000 Backbone
41
NMEA 0183 Device Connection
43
Connect an External Monitor
45
Software Setup
46
Network Settings
47
Radar Settings
51
Own Ship
56
Simulator
57
Maintenance
59
Software Upgrades
60
The Alert System
61
Acknowledging Alerts
62
Alphabetic Alarm Listing
63
Operating Modes Fallback
64
Terms and Abbreviations
65
Spare Parts and Accessories
69
R3016 Spare Parts and Service Packs
70
Technical Specifications
71
Power
72
Menu Tree
73
Dimensional Drawings
74
Other manuals for Simrad R2009
