Simrad R2009 User Manual

Ensure unobstructed access to all operator panels, controls, and relevant switchgear cabinets
in order to enable instant response to alarms.
Whenever it is necessary to disconnect the waveguide from a radar transmitter for
maintenance purpose, the transmitter output should be terminated with a matched load. If
this is not possible, care should be taken. Do not stand in front of an open-ended waveguide
from which power is being radiated.
¼
Note: Main power is always present on the terminal board unless the main break from
the power distribution panel of the vessel is turned off.
Warning: Never look down a waveguide from which power is being
radiated!
Warnings
High voltage
Radar equipment includes high voltage that can cause injury or loss of life. Danger exists only
when the units are opened, exposing internal circuits, as when servicing the equipment.
This radar has been carefully designed to protect personnel from possible injury from high
voltages. Although every effort has been made to eliminate danger to personnel, no
responsibility is accepted for any injury or loss of life suffered in connection with this
equipment.
Trademarks
Navico
®
is a registered trademark of Navico.
Simrad
®
is used by license from Kongsberg.
NMEA
®
and NMEA 2000
®
are registered trademarks of the National Marine Electronics
Association.
SimNet
®
is a registered trademark of Navico.
SD
™
and microSD
™
are trademarks or registered trademarks of SD-3C, LLC in the United
States, other countries or both.
HDMI
®
and HDMI
™
, the HDMI Logo, and High-Definition Multimedia Interface are trademarks
or registered trademarks of HDMI Licensing LLC in the United States and other countries.
Preface | R2009/R3016 User manual
5

Simrad R2009 Specifications

General

Brand	Simrad
Model	R2009
Category	Marine GPS System
Language	English
