Simrad S3009 User Manual

Extension cable
An extension cable can be installed if a total length of more than 20 meters is required
between the transducer and the S3009 or S5100 module.
Ú
Note: A 2 x 2,5/2,5 mm² or a 2 x 1,5/1,5 mm² cable shall be used.
S3009 transducer wiring
The S3009 is equipped with a 7-pin transducer connector at the back of the unit.
1 Red
5 Black
6 / 7 Shield
Not used
1 White
2 Black
3 Shield
1 Unk
nown color
2 Unknown color
3 ShieldDepth GND
Depth -
Depth +
1 Unknown color
2 Unk
nown color
3 Shield Depth GND
Depth -
Depth +
Optional extension cable (B)
7-
pin
c
onnector
Transducer
Junction (E)
Junction (D)
(A)
(C)
Ú
Note: For more details, refer to "Extension cable" on page 28 and "Junction details" on page 30.
Echosounder 7-pin connector details
1
2
3
4
5
6
7
Unit socket (female)
1
2
3
4
5
6
7
Cable plug (male)
Pin Purpose
1 Depth +
2 Speed signal
3 Speed volts
4 Temp +
5 Depth -
6 Depth Gnd (shield)
7 Temp - (shield)
E
D
A
B
C
28
Wiring | S3009 Echo Sounder User Manual
