Simrad S3009 User Manual

S5100 transducer wiring
The S5100 is equipped with three 9-pin transducer connectors.
5 Red
4 Black
1 Shield
Not used
1 White
2 Black
3 Shield
1 Unk
nown color
2 Unknown color
3 ShieldDepth GND
Depth -
Depth +
1 Unknown color
2 Unk
nown color
3 Shield Depth GND
Depth -
Depth +
Optional extension cable (B)
Transducer
Junction (E)
Junction (G)
9-pin
connector
(F)
(C)
Ú
Note: For more details, refer to "Extension cable" on page 28 and "Junction details" on page 30.
Echosounder 9-pin connector details
2
1
9
7
5
4
3
6
8
Unit socket (female)
2
1
9
7
5
4
3
6
8
Cable plug (male)
Pin Purpose
1 Drain/Ground
2 Starboard +
3 Starboard -
4 Transducer TX/RX -
5 Transducer TX/RX +
6 Port +
7 Port -
8 Temp
9 Transducer ID
E
G
F
B
C
Wiring | S3009 Echo Sounder User Manual
29
