REPAIR
0607SE Maintenance Manual 6-21 © Jan 2022
6. Return to the main interface through the Esc key,
lower the platform to the stowed position, and
power off the machine as needed.
Calibrate weight
NOTICE
• To ensure the accuracy of weight calibration,
please perform height calibration before weight
calibration.
• Weight calibration includes no-load calibration
and full-load calibration. Please complete the
calibration with the ECU panel within one cycle as
per the following procedures.
• No-load calibration
1. Lower the platform to the stowed position, and
ensure that the space above the platform allows
the platform to be safely lifted to the maximum
height.
2. Make sure no heavy objects are placed on the
platform.
3. After entering the ECU menu selection mode,
select and enter No-load calibration interface,
and press the Enter key to start automatic
calibration.
Figure 6-21
4. The platform will rise and descend twice
automatically: rise to the highest position and
descend to the stowed position.
5. When the screen displays “No-load calibration
complete”, the no-load calibration is successfully
done.
Figure 6-22
6. Return to the Calibrate weight interface through
the Esc key.
• Full-load calibration
1. Place heavy objects with the same weight as the
rated load of the machine on the platform.
2. Select and enter Full-load calibration interface,
and press the Enter key to start automatic
calibration.
Figure 6-23
3. The platform will rise and descend twice
automatically: rise to the highest position and
descend to the stowed position.
4. When the screen displays “Full-load calibration
complete”, the full-load calibration is
successfully done.
Figure 6-24
5. Return to the main interface through the Esc key,
and power off the machine as needed.
Brake release (for electrically-driven models
only)
1. Choke the wheels of the machine to prevent it from
rolling.
2. Make sure there are no obstacles on the passage.
3. Lower the platform to the stowed position.
4. After entering the ECU menu selection mode, select
and enter Brake release interface, and press the
Enter key for 5s.
Figure 6-25
5. When the screen displays “Brake release
succeeded”, the brake release is successfully done.
Figure 6-26
6. Return to the main interface through the Esc key,
and power off the machine as needed. The setting
will reset automatically after power-off and restart.
No-load calibration
complete
Full-load calibration
complete
