REPAIR
0607SE Maintenance Manual 6-25 © Jan 2022
Figure 6-33
3. The platform will rise and descend for three
times automatically: rise to the highest position
and descend to the stowed position (the first,
second and third ascending and descending
movements are for height calibration, static
calibration and dynamic calibration respectively).
4. When the screen displays “Sensors Have Been
Changed!”, the full-load calibration is
successfully done.
Figure 6-34
5. Return to the main interface through the Esc key,
and power off the machine as needed.
Brake release (for electrically-driven models
only)
1. Choke the wheels of the machine to prevent it from
rolling.
2. Make sure there are no obstacles on the passage.
3. Lower the platform to the stowed position.
4. After entering the ECU menu selection mode, select
and enter “Brake Release” interface, and press the
Enter key for 5s.
Figure 6-35
5. When the screen displays “Brake is Released” and
the horn sounds, the brake release is successfully
done.
Figure 6-36
6. Return to the main interface through the Esc key,
and power off the machine as needed. The setting
will reset automatically after power-off and restart.
Set OL Descent Height
1. Ensure that the space above the platform allows the
platform to be safely lifted to the maximum height
and the machine is horizontally positioned.
2. After entering the ECU menu selection mode, select
and enter “OL Descent Height” interface.
Figure 6-37
3. Raise the platform to a certain height (the desired
OL descent height) with the ground controller.
4. After pressing the Enter key for 5s, the system will
return to the previous interface. Then the OL
descent height is set successfully, and the current
height is set as the OL descent height.
5. Return to the main interface through the Esc key,
lower the platform to the stowed position, and
power off the machine as needed.
Set Drive Limit Height
1. Ensure that the space above the platform allows the
platform to be safely lifted to the maximum height
and the machine is horizontally positioned.
2. After entering the ECU menu selection mode, select
and enter “Drv Limit Height” interface.
Figure 6-38
3. Raise the platform to a certain height (the desired
drive limit height) with the ground controller.
4. After pressing the Enter key for 5s, the system will
return to the previous interface. Then the drive limit
height is set successfully, and the current height is
set as the drive limit height.
5. Return to the main interface through the Esc key,
lower the platform to the stowed position, and
power off the machine as needed.
Set Outdoor Limit Height
1. Ensure that the space above the platform allows the
platform to be safely lifted to the maximum height
and the machine is horizontally positioned.
2. After entering the ECU menu selection mode, select
and enter “Outdoor Limit Height” interface.
Figure 6-39
