REPAIR
0607SE Maintenance Manual 6-33 © Jan 2022
Code Problem Action Limit Solution
54
Lift Up Coil Fault Disable Lifting and Driving
Lift Up Coil Fault: Check the connections to the
Coil’s terminals and make sure they are tight. If so,
check the coil itself to see if it is open or shorted.
55 Lift Down Coil fault
Disable Lifting and Driving
Lift Down Coil Fault: Check the connections to the
Coil’s terminals and make sure they are tight. If so,
check the coil itself to see if it is open or shorted.
56
Right Turn Coil Fault Disable Lifting and Driving
Right Turn Coil Fault: Check the connections to
the Coil’s terminals and make sure they are tight. If
so, check the coil itself to see if it is open or
shorted.
57 Left Turn Coil Fault
Disable Lifting and Driving
Left Turn Coil Fault: Check the connections to the
Coil’s terminals and make sure they are tight. If so,
check the coil itself to see if it is open or shorted.
58
General Brake Coil
Fault
Disable Lifting and Driving
General Brake Coil Fault: Check the connections
to the Coil’s terminals and make sure they are
tight. If so, check the coil itself to see if it is open or
shorted.
59 Parallel Coil Fault
Disable Lifting and Driving
Parallel Coil Fault: Check the connections to the
Coil’s terminals and make sure they are tight. If so,
check the coil itself to see if it is open or shorted.
60 Motor Controller Fault
Disable Lifting and Driving
Motor Controller Fault: Check the connections to
motor and make sure they are tight. If so, check
there are other detail faults.
61
Motor Controller
Current Sensor Fault
Disable Lifting and Driving
Motor Controller Current Sensor Fault: Drive or Lift
Motor may be overheating. Let the lift cool down. If
that does not help, cycle power to reset the Motor
controller. If the problem persists, check the wiring
and if OK, try replacing the Motor Controller.
62
Motor Controller
Hardware Failsafe
Fault
Disable Lifting and Driving
Motor Controller Hardware Failsafe Fault: Cycle
power. If that does not resolve the issue check for
noise sources. If still needed, try replacing the
Motor Controller.
63
Motor Controller
Motor Short Fault
Disable All Motion
Motor Controller Motor Short Fault: Check wiring
first then cycle power. If needed replace controller.
64
Motor Controller SRO
Fault
Disable Lifting and Driving
Motor Controller SRO Fault: Look at motor enable
delay with the Scissor Programmer, it may be too
short. Make sure other Motor Controller
parameters are properly selected.
65
Motor Controller
Throttle Fault
Disable All Motion
Motor Controller Throttle Fault: Check wiring.
Make sure the correct throttle type is selected in
the Motor Controller.
66
Motor Controller
Emergency Reverse
Fault
Disable All Motion
Motor Controller Emergency Reverse Fault:
Ensure that the Emergency Reverse Check
parameter is off in the Motor Controller.
67
Motor Controller HPD
Fault
Disable All Motion
Motor Controller HPD Fault: Look at motor enable
delay with the Scissor Programmer, it may be too
short. Make sure other Motor Controller
parameters are properly selected.
68
Total Voltage Low
Fault 2
Disable All Motion
Total Voltage Low Fault 2: Check battery voltage
and charge if necessary. Check the battery
