16 Extra equipment and accessories Sirona Dental Systems GmbH
16.7 X-ray image viewer on the dentist element Operating Instructions C4
+
59 06 313 D 3382
104 D 3382.201.01.13.02
16.7 X-ray image viewer on the dentist element
Extra equipment
This X-ray image viewer is switched ON or OFF using
the illustrated key on the dentist or assistant element
control panel.
To view intraoral dental images the anti-glare film (1)
must first be attached with two clips. Then fasten the
intraoral dental images with the third clip over the
cut-out.
16.8 X-ray image viewer on the lamp support tube
Extra equipment
This X-ray image viewer is switched ON or OFF using
the illustrated key on the dentist or assistant element
control panel.
To view intraoral dental images the anti-glare film (1)
must first be attached with two clips. Then fasten the
intraoral dental images with the third clip over the
cut-out.
1
1
