8 Patient positions Sirona Dental Systems GmbH
8.1 Flat headrest Operating Instructions C4
+
59 06 313 D 3382
30 D 3382.201.01.13.02
8 Patient positions
8.1 Flat headrest
The headrest must be adjusted manually.
To do this, take the load off the backrest and pull out or
push in the headrest using the handle (1).
The head pad (2) is held magnetically.
DANGER
A strong magnet is integrated in the underside of the
head cushion (2) which could affect a nearby cardiac
pacemaker.
Therefore, please avoid bringing the magnet in close
proximity of a cardiac pacemaker of a patient, user or
technical personnel.
In addition, direct contact of the head cushion with
magnetic cards can lead to a data loss.
8.2 Articulated headrest
The headrest must be adjusted manually.
To do this, take the load off the backrest and pull out or
push in the headrest using the handle (1).
Tilt the headrest backward using the locking button (2).
DANGER
Tilt the headrest forward by simply pulling it out.
1
2
1
2
