Sirona C4+ - Controls and Functional Elements; Dentist Element Control Panel

Sirona Dental Systems GmbH 4 Controls and functional elements
Operating Instructions C4
+
4.1 Control panel on the dentist element
59 06 313 D 3382
D 3382.201.01.13.02
15
4 Controls and functional elements
4.1 Control panel on the dentist element
Control panel
System status indication display and Mode
key
AMALG appears when the amalgam rotor needs to be
replaced.
DESINF is flashing when DENTOSEPT P must be
refilled.
A appears when user A is selected.
B appears when user B is selected.
Mode key with + / – keys for programming basic set-
tings.
In addition to the settings in the Mode dialog, the follow-
ing direct settings can be made with the
+ / – keys:
• Intensity of the instrument lights
• Intensity of the operation light
• Tumbler filling time
• Cuspidor flushing time
100
A/B
50
40
20
0.2
rpm x 1000
1
SS
11
00
22
Mode
–
–
+
RPM
A
AMALG DESINF
C4
+
