4 Controls and functional elements Sirona Dental Systems GmbH
4.1 Control panel on the dentist element Operating Instructions C4
+
59 06 313 D 3382
16 D 3382.201.01.13.02
 Main functions – dark blue keys
Quick setting keys for instrument intensity and
speed
for electric motors and SIROSONIC L ultrasonic scaler
Spray ON / OFF
on burr drives
Chip blower
on burr drives
Counterclockwise rotation
for electric motor
Instrument light ON / OFF
Pressing this key for some time displays the light inten-
sity settings dialog.
Mouth rinsing position chair program.
with last position memory function (freely programma-
ble)
Chair program 0
Entry/exit position (freely programmable)
Chair programs 1 and 2
(freely programmable)
NOTICE
i
The four program keys are also used for reprogramming
the chair programs.
100
50
40
20
0.2
rpm x 1000
1
A
%
INSTR. LIGHT
SS
00
22
11
