9 Dentist element and instrument functions Sirona Dental Systems GmbH
9.10 Satelec Mini L.E.D. curing light Operating Instructions C4
+
59 06 313 D 3382
50 D 3382.201.01.13.02
To start the polymerization cycle, briefly press the ON/
OFF switch (6). This is confirmed by an audible signal.
In each mode, an audible signal sounds every 5 sec-
onds.
The end of the cycle is also indicated by an audible sig-
nal. You may interrupt the cycle at any time though by
lightly pressing the ON/OFF switch.
Technical data
6
General technical data
Model: Mini L.E.D.
Weight of handpiece without
hose:
105 g
Dimensions: dia. 23mm x
240mm
Power supply of handpiece: 5 V DC / 2 A
Thermal safety: Overheat protection
Optical specification
Wavelength: 420nm – 480nm
Intensity dia. 7.5mm
(standard version):
1100mW/cm
2
Intensity dia. 5.5 mm (optional,
available from Satelec):
2000 mW/cm
2
Power: 450 mW – 500 mW
Laser power: < 1mW
