SKF Matrix Series User Manual

4 Structure and function
Matrix MAX6
1 Multi-shell plastic housing
2 Connection of slave actuator (optional)
3 Connection of operation element
4 Connection of power line
5 Hinge head
6 Bracket
7 Casing tube
8 Actuator
9 Fork head of the actuator
10 Linear unit
4.1 Overview
4.1.1 Matrix MAX1 and MAX3
1
2
3
4
5
6
7
8
9
Fig. 5
4.1.2 Matrix MAX6
1
2
3
4
5
6
7
8
9
10
Fig. 6
Matrix MAX1 and MAX3
1 Connection cable on control
2 Multi-shell plastic housing
3 Motor part
4 Hinge head
5 Bracket
6 Casing tube
7 Actuator
8 Fork head of the actuator
9 Linear unit
25
