6.5 Connection to operating
element
6.5.1 Connect MAX1 and MAX3 to operating
element
!
Note!
The device is connected to the operating element via an
external control. († Separate operating manual of the control
and the operating element).
6.5.2 Connect MAX6 to operating element
!
Note!
The device is connected directly to an electric or pneu-
matic operating element. Adhere to the operating instructions
for the operating elements in regard to the connection
(† Separate operating manual).
Risk of injury and material damage due to third party
operating element
The use of a third party operating element may lead to signifi-
cant injuries or material damage.
In conjunction with the use of a third-party operating
element, the manufacturer does not assume any liability for
damage that may be caused.
Therefore:
• Only use the manufacturer’s SKF operating element.
WARNING
47
