SKF MKU Series Assembly Instructions

62
Table 23
Spare parts
No.
Units
Material number
Designation
Description
1
1
996-000-947
Pressure limiting valve 32 bar
for oil
1
996-002-197
Pressure limiting valve 30 bar
for fluid grease
2
1
MKF.U012
Pressure relief, compl. for fluid grease
for fluid grease
1
MKU.U012
Pressure relief, compl. for oil
for oil
3
1
MKF.U013
Pressure gauge for fluid grease
for fluid grease (without throttle)
1
MKU.U013
Pressure gauge for oil
for oil (with throttle)
4
1
MKF1.U5+924
Motor with shaft 24 V DC
for 2- and 3-liter fluid grease units
1
MKF2.U1+XXX
1)
Motor with shaft
for 2- and 3-liter fluid grease units
1
MKF2.U2+XXX
1)
Motor with shaft
for 6-liter fluid grease units
1
MKF2.U5+924
Motor with shaft 24 V DC
for 6-liter fluid grease units
1
MKU1.U5+924
Motor with shaft 24 V DC
for 2- and 3-liter oil units
1
MKU2.U2+XXX
1)
Motor with shaft
for 2- and 3-liter oil units
1
MKU2.U3+XXX
1)
Motor with shaft
for 6-liter oil units
1
MKU2.U5+924
Motor with shaft 24 V DC
for 6-liter oil units
5
1
WVN501-32.2x3
O-ring
Sealing between motor and lid
6
4
911-204-122
Cheese-head screw
Motor fastening
1
7
1
WVN501-5.28x1.78
O-ring
Sealing between pump and flange pipe
8
1
ZP110-2
Gear pump
Delivery rate 0.1 l/min
1
ZP120-2
Gear pump
Delivery rate 0.2 l/min.; 0.1 l/min. with 24 V DC
1
ZP150-2
Gear pump
Delivery rate 0.5 l/min.; 0.2 l/min. with 24 V DC
9
2
834-240-018
Screw M3×25 Tx10
Fastening for ZP110-2 and ZP120-2
2
834-250-034
Screw M3×30
Fastening for ZP150-2
10
1
179-340-090
Capacitor 4 UF/450 V
Capacitor for 230 V AC (+428)
1
179-340-091
Capacitor 16 UF/220 V
Capacitor for 115 V AC (+429)
11
1
176-112-020
Pressure switch 20 bar
1 functioning as NO contact
12
1
WVN501-10.5x1.5
O-ring
Seal for pressure switch
13
1
MKF.U016
Level switch assy
for fluid grease in 2- and 3-liter unit (NC contact)
1
MKF.U116
Level switch assy
for fluid grease in 6-liter unit (NC contact)
1
MKU.U015
Lubricant level switch assy
for fluid grease in 2- and 3-liter unit (NO contact
)
1
MKU.U016
Lubricant level switch assy
for oil in 2- and 3-liter unit (NC contact)
1
MKU.U115
Lubricant level switch assy
for oil in 6-liter unit NO contact
1
MKU.U116
Lubricant level switch assy
for oil in 6-liter unit NC contact
14
4
911-205-161
Cheese-head screw
Reservoir fastening for 2 liters
6
911-205-181
Cheese-head screw ZN
Reservoir fastening for 3 and 6 liters
15
1
993-000-169
Reservoir assy
2 liter plastic reservoir with seal
1
B3.U180
Reservoir 3 liter
3 liter metal reservoir with seal
1
BK3.U147
Reservoir 3 liter
3 liter plastic reservoir with seal
1
BK6.U180
Reservoir 6 liter
6 liter plastic reservoir with seal
16
1
898-660-056
Cap
Cap for 2-liter unit
1
898-660-052
Cap
Cap for 3- and 6-liter unit
17
1
MKU.U009
Filler neck assy
for oil (with strainer)
1
MKU.U019
MKU.U019 Filler neck assy
for oil (with strainer), 3-liter lid
1
MKF.U009
Filler neck assy
for fluid grease (without strainer)
1
MKF.U019
Filler neck assy
for fluid grease (without strainer), 3-liter lid
