Table 8
Technical connection data
Designation
Value
<Content>
Lubricant level switch for oil (opens when fill level is too low)
Switching voltage range
10 to 36 V DC / 10 to 25 V AC
Switched current (resistive load)
3)
≤ 0.25 A
Pumped media switching capacity (resistive load)
≤ 3 W/VA
Lubricant level switch for oil (closes when fill level is too low)
Operating viscosity
20–1500 mm 2 /s
Switching voltage range
10 to 36 V DC/10 to 25 V AC
Switched current (resistive load)
3)
≤ 0.25 A
Switching capacity (resistive load)
≤ W/VA
Lubricant level switch for fluid grease (opens when fill level is too low)
Operating voltage range
10 to 36 V DC
Output voltage (resistive load)
3)
≤ 0.25 A
Power consumption without output load
< 10 mA (24 V), < 15 mA (36 V)
Short-circuit-proof and reverse voltage protection
Yes
Pressure switch (NO contact)
Nominal pressure
20 bar
Switching voltage range
10 to 36 V DC/10 to 25 V AC
Switched current (resistive load)
3)
≤ 1 A
Switching capacity (resistive load)
≤ 10 W/VA
Additional input power for units with control unit
IG38-30 / IZ38-30
4 W
IG54-20 / IGZ36-20
8 W
1) Based on an operating viscosity of 140 mm 2 /s (cSt) at a back pressure of p = 5 bar.
2) The operating mode S3 (periodic duty) describes the ratio of pump cycle time to subsequent downtimes time. If the relative ON-time is
20 % and the duty cycle time is 1.25 to 25 min., then the limit values are as follows:
Min. duty cycle time: 1,25 min×0,2 = 0,25 min. Pump cycle time with subsequent downtime of 1 min. Max. duty cycle time: 25 min×0.2 =
5 min. Pump cycle time with subsequent downtime of 20 min.
3) When switching inductive loads, take appropriate measures to protect contacts.
4) Minimum short-circuit current of 6 A must be ensured.
4.2 Order code for MKU gear pump units
M
K
U
-
1
0
0
0
+
Product series
MKx
MKx pump
Lubricant
U
for oil
Delivery rate
1
0.1 l/min
"
"
"
-
2
0.2 l/min
-
"
"
"
5
0.5 l/min
-
"
"
"
Lubricant reservoir, control unit
Lubricant reservoir
1
2
3
4
2 liter
plastic
3 liter
plastic
3 liter
metal
6 liter
plastic
