SKF SF05A User Manual

53
7.8 Terminal block sequence BSS-051015 and BSS-12030
No. Meaning
1 and 2
Operating voltage 24V AC/DC, pole 1
3 and 4
Operating voltage 24V AC/DC, pole 2
5 and 6
Casing grounding
7
Connected No 8
8
Connected No 7
21
Sensor 1 +, brown wire
22
Sensor 1 -, blue wire
23
Sensor 2 +, brown wire
24
Sensor 2 -, blue wire
25
Sensor 3 +, brown wire
26
Sensor 3 -, blue wire
27
Sensor 4 +, brown wire
28
Sensor 4 -, blue wire
29
Sensor 5 +, brown wire
30
Sensor 5 -, blue wire
31
Sensor 6 +, brown wire
32
Sensor 6 -, blue wire
33
Sensor 7 +, brown wire
34
Sensor 7 -, blue wire
35
Sensor 8 +, brown wire
36
Sensor 8 -, blue wire
37
Sensor 9 +, brown Wire
38
Sensor 9 -, blue wire
39
Sensor 10 +, brown wire
40
Sensor 10 -, blue wire
41
Alarm contact, position 1 (a)
42
Alarm contact, position 1 (b)
43
Alarm contact, position 2 (a)
44
Alarm contact, position 2 (b)
45
Alarm contact, position 3 (a)
46
Alarm contact, position 3 (b)
47
Alarm contact, position 4 (a)
48
Alarm contact, position 4 (b)
49
Alarm contact, position 5 (a)
50
Alarm contact, position 5 (b)
51
Alarm contact, position 6 (a)
52
Alarm contact, position 6 (b)
53
Alarm contact, position 7 (a)
54
Alarm contact, position 7 (b)
55
Alarm contact position 8 (a)
56
Alarm contact, position 8 (b)
57
Alarm contact, position 9 (a)
58
Alarm contact, position 9 (b)
59
Alarm contact, position 10 (a)
60
Alarm contact, position 10 (b)
