Ski-Doo Summit 583 1998 - Chaincase

Section 05 TRANSMISSION
Subsection 07 (CHAINCASE)
05-07-1
CHAINCASE 0
S-Series without Reverse Gear
SYNTHETIC CHAINCASE OIL
HUILE SYNTHÉTIQUE POUR CARTER
A03D2OS
Chaincase
oil
2
1
45 to 75 N•m
(33 to 55 lbf•ft)
3
27
4
5
6
23
7
Loctite
242
12
46 N•m
(34 lbf•ft)
15
Loctite
271
14
13
16
17
14
21
22
Loctite
242
18
20
11
Loctite
609
28
26
10
9
24
25
8
FLAT RATE
PARTS
