Section 06 ELECTRICAL
Subsection 06 (TESTING PROCEDURE)
06-06-7
M: Male
F: Female
IGNITION SYSTEM TESTING (S-Series liquid cooled models and Skandic WT LC)
Part
Test to be
performed
Wire
color
Multimeter
probe
connection
Resistance Ω Voltage V
Note
Value
(Ohms)
Multimeter
scale
Value
(Volts)
Multimeter
scale
Stop switch
Running
insulation
BK and
BK/YL
2-01C-F
and
2-02-M
0.L
00.0
M
Ω
——
No stop switch must be
operational.
Continuity in
stop position
BK and
BK/YL
2-01C-F
and
2-02-M
00.0 -
00.5
00.0
Ω
——
At least one stop switch must be
operational.
Ignition
generator
coil
Output
RD
BK/RD
2-04A-F
and
2-04B-F
10.0 -
15.0
00.0
Ω
10.0 -
13.5
00.0
VAC
No stop switch must be
operational.
BK
BK/RD
2-04C-F
and
2-04B-F
0.L
00.0
Ω
——
BK
RD
2-04C-F
and
2-04A-F
0.L
00.0
Ω
——
Ground
continuity
BK and
engine
2-04C-1-F
and
4-20-1-M
00.0 -
00.5
00.0
Ω
—— —
Ground
continuity
BK and
engine
2-01C-1-F
and
engine
00.0 -
00.5
00.0
Ω
——
The term "engine" refers to the
engine metal parts connected to
the magneto housing.
Ignition
module
Output
voltage
BK and
WH/BL
3-01-2-F
and
3-01-1-F
——
4.5 -
8.0
00.0
VAC
—
High
voltage coil
Primary
winding
resistance
BK and
WH/BL
3-01-2-M
and
3-01-1-M
0.00 -
00.9
00.0
Ω
——
Disconnect WH/BL wire from coil in
order to take measurements.
Secondary
winding
resistance
(spark plug
cap included)
—
Spark plug
caps
11.5 K -
14.5 K
00.0
K
Ω
-
CAUTION
Do not measure high voltage coil output voltage.
Secondary
winding
resistance
—
Spark plug
wires
19.5 K -
26.5 K
00.0
K
Ω
-
CAUTION
Do not measure high voltage coil output voltage.
Secondary
winding
voltage
—
On spark
plug wire
and engine
— — 0.1 - 1.4
0.00
VAC
The measurement must be taken on
the spark plug wire (without the
spark plug).
Insulation
Cap
and
WH/BL
In cap and
3-01-1-M
0.L
00.0
Ω
——
—
Cap
and BK
In cap and
3-01-2-M
0.L
00.0
Ω
——
Spark plug
cap
Cap
resistance
—
Spark plug
side and
wire side
4.0 K -
6.0 K
00.0
K
Ω
—— —
