SKOPE Reflex Underbench Fridge and Freezer
Wiring
Service Manual
CAUTION
Some connector colours vary depending on date of manufacture.
Refer to the Plug type/colour column in the table below for colour variations.
After unplugging connectors, ALWAYS ensure you have reconnected the plugs
correctly, as operational faults may occur if incorrect. SKOPE recommends
photographing the wiring setup before unplugging for future reference.
LEGEND
Internal Cartridge Junction Box Sockets/Plugs
Name Description
Plug type/colour
Before Feb. 2020 From Feb. 2020
Inlet IEC Cabinet Socket/Plug IEC IEC
S1/P1 Not Used – –
S2/P2 Cartridge Junction Box to Controller Signal Socket/Plug White 6-way White 6-way
S3/P3 Cartridge to Controller Power Socket/Plug Blue 4-way Black 4-way
S4/P4 Heater Wire Cartridge Socket/Plug Black 3-way Black 3-way
S5/P5 Heater Wire Cartridge Socket/Plug 2 Black 3-way Black 3-way
S6/P6 Light Cartridge Socket/Plug White 3-way White 3-way
S7/P7 Cartridge to Controller Power Socket/Plug 1 Red 4-way Orange 4-way
S8/P8 Door Sensor Socket/Plug White 2-way White 2-way
S9/P9 Compressor Cartridge Socket/Plug Blue 4-way Blue 4-way
S10/P10 Evaporator Sensor Socket/Plug Black 2-way Black 2-way
S11/P11 Cabinet Sensor Socket/Plug Blue 2-way Blue 2-way
S12/P12 Defrost Element Socket/Plug Yellow 4-way Yellow 4-way
S13/P13 Condenser Motor Cartridge Socket/Plug Red 4-way Red 4-way
S14/P14 Evaporator Motor Cartridge Socket/Plug White 4-way White 4-way
S15/P15 Condenser Sensor Socket/Plug Red 2-way Orange 2-way
S16/P16 Ambient Sensor Socket/Plug White 2-way White 2-way
S17/P17 Programming/Comms Port Socket Blue 4-way Blue 4-way
S18/P18 LED Driver DC Out Put Socket/Plug Red 2-way Red 2-way
S19/P19 LED Lighting Loom Socket/Plug Yellow 4-way Green 4-way
S20/P20 Evaporator Extension Flex Socket/Plug White 4-way White 4-way
S21/P21 Condenser Extension Flex Socket/Plug Red 4-way Red 4-way
T1 Cartridge Terminals – –
