76
SJ12 E, SJ16 E, SJ20 E243762ABA
Section 8 – Labels
Left view
Left view (continued)
Description Label Pictorial
9
Service pin
▪
The service pin is located in the pin clamp on the mast.
▪
You can use the service pin when you do service or
maintenance on the MEWP.
▪
Insert the service pin through the slots until the end of the pin
is fully through the second slot.
9
9
