Skyjack SJ12 E - Page 77

77
SJ12 E, SJ16 E, SJ20 E
243762ABA
Left view Section 8 – Labels
Description Label Pictorial
10
Base controls
▪
Turn and hold the lower/neutral/raise switch to lower or
raise the platform.
▪
Select the off position to turn off power to the MEWP,
the base position to energize the base controls, or the
platform position to energize the platform controls.
▪
Push the emergency-stop button to disconnect power
to the control circuit. Pull the emergency-stop button to
connect the power again.
▪
Push the power circuit breaker to reset the power circuit
breaker.
Winch/tow/push procedure
Refer to the operation manual.
1. Release the brakes manually. Refer to Section 6.2.
2. Push, winch, or tow the MEWP to the necessary location.
3. Put the MEWP on a rm, level surface.
4. Push the emergency-stop button to engage the brakes.
TM
230744ACZZ
Cut out Cut out Cut out
Cut out
Cut out
Cut out
1
2
TM
+
3
4
3 sec
Cut out
Left view (continued)
10
