Slican IPM-032
4 Port modules
IPM servers have a modular construction. A server extension module is an extension card. All cards
are placed in the slots designed for them in the base board.
Name Designation
STAND-ALONE CONTROLLER IPM1APU
LOW-Cost stand-alone controller IPM1LPU
Route card E1 (ISDN-PRA 30B+D) IPM1E1
2 connector card ISDN-BRA ext./int. IPM2ST
Card for 4 digital system phone ports IPM4CTS
Analogue internal 4 ports card IPM4AB
2 public line trunk card and 2 analogue internal ports IPM2CO2AB
2 gsm port card IPM2GSM
1 gsm port card IPM1GSM
2 relay and 2 sensor card IPM2RL2SN
32VoIP* module IPM32VOIP
Shelf power supply unit card IPM1PS
Shelf power supply card (installed only with IPM1LPU controller) IPM1LPS
Batteries management sub module SM.3BATC
DSP sub module – 8 channels G.729 SM.DSP-2V
Analogue modem sub module SM.DSP-AM
ELECTRONIC SERVER NUMBER SUB MODULE SM.SDN
NOTE!
Each time if card is replaced or mounted, make sure that the screws fixing the front panel to the server
shelf are properly tightened to achieve effective protection against any over voltage that may occur in
the added telecommunication lines. Disconnect the unit from the power network when performing
such activities.
Issue 1.01 19
