2.2.1 List of servers and processing units of IPM-032 system
The combination of the variants listed above gives:
″
IPM-032.A8x4.2U - "Alone" server, up to 32 ports, 2U-19" housing. Controller
IPM1APU, power pack MPS-36-65, power module IPM1PS, base board 8 slots IPM8BAZ.
″
IPM-032.A6x4.WM - "Alone" server, up to 24 ports, wall mounted housing.
Controller IPM1APU, power pack MPS-36-65, power module IPM1PS, base board 6 slots
IPM6BAZ.
″
IPM-032.L8x4.2U - "LowCost" server, up to 32 ports, housing 2U-19". Controller
IPM1LPU, power pack MPS-36-45, power module IPM1LPS, base board 8 slots IPM8BAZ.
″
IPM-032.L6x4.WM - "LowCost" server, up to 24 ports, wall mounted housing.
Controller IPM1LPU, power pack MPS-36-45, power module IPM1LPS, base board 6 slots
IPM6BAZ.
2.3 Marking of terminals (port outputs)
The physical server terminal number has the following format:
X-Y-Z
where:
X – no. of server processing unit: 1,
Y – slot number: 1...6 (for WM), 1...8 (for 2U)
Z – port number of the port card: 1...4.
Slot number
Shelf number
1 2 3 ... 6 7 8
1
(shelf)
1-1-Z 1-2-Z 1-3-Z ... 1-6-Z 1-7-Z 1-8-Z
Table 1.: Terminal numbering in servers IPM-032
