Technical documentation
4.11.2 Power supply card IPM1LPS for operation with IPM1LPU controller
Module name: IPM1LPS Short description of the card:
Print name: IPM1LPSv0 The card is responsible for supplying the correct voltages
necessary for server operation. This version of the power
supply card does not enable installation of the SM.3BATC
sub module to support accumulators
View of the card and front panel (for server version 2U)
View of the card and front panel (for server version WM)
Card installation:
The controller card is installed in the base board slot marked Slot PS.
Description of LEDs on the front panel:
LED PS ON
• lit – server active, powered from a 230V system,
• off – server turned off.
38
