4.2.2 Controller card IPM1LPU - "LowCost”
Print name: IPM1PUv0a Short description of the card:
The controller card is the main server port. It is
responsible for managing processes in the system.
It also supports the VoIP (g.711a) function and
EbdRec. This version of processor unit has limited
functionalities: 4 VoIP channels, no support for
IPM1E1, IPM32VoIP cards and submodules SM.DSP-
2V and SM.DSP-AM.
Card marking: IPM1LPU
View of the card and its front panel:
Installing the card in the server:
The controller card is placed in the base board slot marked Slot PU. SDN sub module is also installed
in this module.
Description of LEDs on the front panel
The same as with controller IPM1MPU (see page 21)
Description of outputs on the front panel:
USB – a Mini-USB port for communication with a computer (e.g. ConfigMAN)
LAN – RJ-45 port for internal router (MAC address on the label)
Meaning of LEDs on RJ45 ports (see page 21)
Description of outputs on the card (PCB)
Identical to IPM1MPU (see page 22)
Controller format:
Procedure identical to IPM1MPU (see page 22)
Quick recovery of previous version of firmware:
Procedure identical to IPM1MPU (see page 22)
Notes on use of SD memory cards as a storage media.
Notes identical to IPM1MPU (see page 22)
Battery replacement 2032 3V.
Procedure identical to IP1APU (see page 22)
Issue 1.01 23
