Slican IPM-032
4.9 Automation and notification card
Print name: IPM2RL2SNv0 Short description of the card:
These cards enable the use of a server to perform
automation and notification functions.
Card marking: IPM2RL2SN
View of the card
Installation of a card in the server:
This type of card can be installed in any of the slots numbered from 1 to 8 (6 for IPM-032.WM).
Ports on the card:
These cards have the following ports:
• RL1, RL3 – REL (relay)
• SN2, SN4 – SNS (sensor)
REL relay port work modes:
• NO – Normally open. Max load 42VAC/0.5A, 42VDC/1A
• NC Normally closed. Max load 42VAC/0.5A, 42VDC/1A
• VON12 – activating 12 VDC supply. Max charge admitted 200 mA
• VOFF12 – deactivating 12Vdc supply. Maximum charge: 200 mA
• VON24 – activating 24 VDC supply. Maximum charge: 100 mA
• VOFF24 – Deactivating 24VDC supply. Maximum charge: 100 mA
The required relay work mode is selected by putting jumpers marked REL1 and REL3 in the correct
positions.
SNS sensor port work modes:
