Technical documentation
4.3 Submodules installed in the controller
4.3.1 Electronic server number sub module – SDN
Module name:
SM.SDN Short description of the card:
The electronic server number sub-module is a physical
assembly whose memory contains the server's factory
number. If the server number differs from the number
in the sub module, or if it does not have any number,
the licences assigned to the server will not be active.
Print name: SDNv0
Types of cards: SDN
View of the SDB submodule card:
Installing the submodule in the server:
The SDN sub module card is installed on the controller card.
4.3.2 Sub module DSP-2V (VoIP codecs) does not apply to IPM1LPU
Submodule name: SM.DSP-2V Short description of the submodule:
A submodule expanding the availability of audio
codecs: G.729 and G.711µ.
Print name: DSP2Vv0
Submodule marking: DSP-2V
View of DSP-2V submodule:
Installing the submodule in the server:
The DSP sub module should be installed on the main controller card in the location marked SM.DSP.
If there is a SD.DSP-AM module installed in this location, remove it and reinstall on SM.DSP-2V by
creating a “sandwich”.
4.3.3 Sub module DSP-AM (analogue modem) does not apply to IPM1LPU
Sub module name: SM.DSP-AM Short description of the sub module:
The sub module enables modem transmission for
remote server configuration.
Print name: DSPTMODv0
Submodule marking: DSP-AM
View of DSP-2V sub module:
Installing the submodule in the server:
The DSP sub module should be installed on the controller card in the location marked SM.DSP. If
there is a SD.DSP-2V module installed in this location, then install the SM.DSP-AM installed on it.
