Slican IPM-032
4.10 GSM trunk cards
4.10.1 IPM2GSM card (to 2SIM)
Print name: IPM2GSMv0 Short description of the card:
GSM trunk cards are designed to support direct voice
calls and SMSs to the mobile communications
network. To enable their operation, external aerials and
SIM cards are required.
Card marking: IPM2GSM
View of the card and its front panel:
Installation of a card in the server:
This type of card can be installed in any of the slots numbered from 1 to 8 (6 for IPM-032.WM). To
install a SIM card, pull out the shelf and remove cover (IPM-032.EU) or remove covers (IPM-
032.WM).
Issue 1.01 35
