Using Microscope mode
The SMART Document Camera enables you to view the microscope stage through the document
camera without additional attachments.
g To display a microscope slide
1. Place a slide or object on the stage of the microscope.
2. Focus the microscope so that the subject is in sharp focus.
3. Position the microscope under your document camera so the camera lens is aligned with the
microscope eyepiece.
C C A U T I O N
Ensure you do not hit your document camera lens with the microscope. This could damage
your document camera’s lens.
4.
Press the Camera view button on the control panel.
5. Press Menu on the control panel.
6. Select the Image Setting menu.
7. Use the up and down arrow buttons to select Microscope mode, and then press Enter .
8. Use the up and down arrow buttons to select On, and then press Enter .
Using the Camera view’s on-screen display
menu
You use the on-screen display menu to adjust several settings for your document camera.
g To open the Camera view’s on-screen display menu
1. Set your document camera to Camera view.
2. Press the Menu button on the control panel.
The on-screen display menu appears.
3. Press the up and down arrow buttons on the control panel to navigate to a menu item.
4. Press the left and right arrow buttons to navigate forward or backward through menu items.
5. Press Enter to select a menu item.
C H A P T E R 5
Using your SMARTDocumentCamera in Camera view
29
