Connecting The Receiver
14 EN Smart MX 04
Connecting The Receiver
Attention!
Check that connections of all equipment and the antenna are
proper before connecting the receiver to the mains.
Figure 4: connection scheme
Connecting The Satellite Antenna
Connect the cable of the satellite antenna with the receiver. Screw the
F-connector of the cable to the LNB IN socket of the receiver.
