Connecting The Receiver
Smart MX 04 EN 15
Connecting The TV-Set
Connect your TV-Set with the Scart output for TV. Alternatively you can also
use the connectors AUDIO-L, AUDIO-R and VIDEO.
If the receiver has a modulator, you can connect the RF-OUT of the receiver
with the
antenna input of the TV-Set. If you want to receive programs as well
via the house antenna, you must connect the RF-IN socket of the receiver with
the antenn
a socket in your house.
When all antenna cables are connected, you can select a free channel on your
TV-Set and start the channel search. Please look for details in the user
manual of your TV-Set.
The output channel of the modulator is pre-set to channel 38.
Connecting A Dolby-Digital Device
If you want to connect a Dolby-Digital device, you can connect it with a coaxial
cable to the digital output (SPDIF) of the receiver. For connecting to the Dolby-
Digital device please read its user manual.
Operation
After connecting all devices, you can plug in the mains supplies of all
connected devices and switch them on.
