HGMS62 Split Type Genset Controller User Manual Page 21 of 58
No.
Function
Size
Remarks
13
Relay 250V AC volts free (N/O) output (pluggable),
rated 10A.
14
Relay common point.
15
Temp. Sensor Input
1.0mm
2
Connect temperature sensor.
16
Pressure Sensor Input
1.0mm
2
Connect pressure sensor (resistance, current,
voltage sensor are all ok).
17
Level Sensor Input
1.0mm
2
Connect level sensor.
18
Aux. Sensor 1 Input
1.0mm
2
Connect aux. resistance type sensor.
19
Aux. Sensor 2 Input
1.0mm
2
Connect aux. sensor (resistance, current, voltage
sensor are all ok).
20
DC 5V Voltage Output
1.0mm
2
Provide 5V power for voltage type sensor.
21
Sensor COM
1.0mm
2
B- has connected inside controller.
22
Aux. Input 1
1.0mm
2
Ground (B-) connected is active.
23
Aux. Input 2
1.0mm
2
24
Aux. Input 3
1.0mm
2
25
Aux. Input 4
1.0mm
2
26
CAN H/MP1
0.5mm
2
HGMS62MCAN: this terminal connects ECU CANBUS
interface, 120Ω shielding line recommended to use,
its single end should be grounded.
HGMS62M: connects speed sensor, shielding line is
recommended to use, no. 27 has connected B- inside
the controller.
27
CAN L/MP2
0.5mm
2
28
CT A Phase Monitoring
Input
2.5mm
2
Externally connect current transformer secondary
coil (rated 5A).
29
CT B Phase Monitoring
Input
2.5mm
2
30
CT C Phase Monitoring
Input
2.5mm
2
31
CT COM
2.5mm
2
32
CB+
1.5mm
2
Connect external starting battery positive. This
terminal and terminal 3 of connector C has been
connected inside controller.
33
CB-
1.5mm
2
Connect external starting battery negative. This
terminal and terminal 4 of connector C has been
connected inside controller.
34
ACT1
1.5mm
2
Connect external actuator. This terminal and
terminal 10 of connector B has been connected
inside controller.
35
ACT2
1.5mm
2
Connect external actuator. This terminal and
terminal 7 of connector B has been connected inside
controller.
