3. Product Specifications
3.1 Basic specifications
The basic specifications of this controller are as follows:
Item Specifications
Compatible motor Step Motor (Servo / 24VDC)
Power supply
(*1) (*3)
Power voltage:24VDC +/-10%
Max.current consumption: 3A(Peak 5A)
(*2)
(for both of motor drive power,control power,
stop,lock brake release)
Parallel input 11 inputs (photo-coupler isolation)
Parallel output 13 outputs (photo-coupler isolation)
Compatible encoder Incremental A/B phase(800 pluse/rotation)
Serial communication Conforming to RS485.
Memory EEPROM
LED indicator 2 off LED’s (green and red)
Lock control Forced-lock release terminal
Cable length
I/O cable: 5m or less
Actuator cable: 20m or less
Cooling system Natural air cooling
Operating temperature
range
0– 40
o
C(No freezing)
Operating humidity range 90％RH or less (No condensation)
Storage temperature range -10 – 60
o
C (No freezing)
Storage humidity range 90％RH or less (No condensation)
Insulation resistance
Between external terminals and case
50M (500VDC)
Mass
150g(screw mount type)
170g(DIN rail mount type)
(*1) The controller power supply do not use the power supply of “rush-current restraining type”.
(*2) The power consumption changes depending on the actuator model.
Please refer to the specifications of actuator for more details.
(*3) When conformity to UL is required, the electric actuator and controller should be
used with a UL1310 Class 2 power supply.
