7. Setting Data Entry
In order to move the actuator to a specific position, it is necessary to setup the patterns of operations with
a PC (with the controller setting software) or the teaching box. This setup data input by the software or
teaching box will be recorded in the memory of the controller.
For the controller setting software and the teaching box, there are two available modes (the Easy mode
and the Normal mode). You can select the appropriate one depending on the operation.
* Easy mode
In Easy mode, you can start up the actuator by entering only a limited number of settings with
the controller setting software and the teaching box.
* The combination of settings you need to setup will change depending on the type of actuators
(combination of data can be selected.)
* Normal mode
In Normal mode, you can make a further detailed setup (conditions for actuator and
controller, etc.) than the Easy mode.
You can change three kinds of setting data, “Step data,” “Basic parameter” and “Return to
origin parameter” in this mode.
7.1 Step data
A “step data” is the setting data mainly describing the movement of the actuator. Total 64 step data (12
types) can be handled with this controller. Each step data will become effective as soon as it is recorded
into the controller.
(Example) Step data on the PC (controller setting software) screen [Normal mode]
No. Move
Speed
mm/s
Position
mm
Accel
mm/s
2
Decel
mm/s
2
PushingF
％
TriggerLV
％
PushingSp
mm/s
Moving F
％
Area1
mm
Area2
mm
In pos
mm
0 Absolute 100 20.00 1000 1000 0 0 0 100 18.00 22.50 0.5
1 Absolute 50 10.00 1000 1000 70 60 5 100 6.0 12.0 1.5
63 Absolute 20 5.00 500 500 0 0 0 100 3.0 8.0 1.2
