[2] Positioning operation
- Procedures-
(1) Input step dat
a No. (IN0 to IN5)

(2) DRIVE is turned ON.
Scan the step data number (from IN0 to IN5).
* Then, if DRIVE is turned OFF, the step data
number will be output (from the output OUT0 to
OUT5).

(3) BUSY is turned ON.
(The positioning operation starts.)

(4) When INP turns ON and BUSY turns OFF,
the positioning operation will be completed.
Power
IN0～5
SVON
DRIVE
OUT0～5
BUSY
SVRE
SETON
INP
External Lock
Output
Input
Speed
24V
0V
OF
F
ON
ON
OF
F
ON
OF
F
0m
m
･
･
・
・
･
･
･
･
･
･
･
･
･
Min15m
s
Min15m
s
-Timing chart-
Output the
s
t
ep
da
t
a
n
o
.
If the actuator is within the “In
position” range, INP will be turned
ON but if not, it will remain OFF.
Scan the step
data no.
Input the step
data no.
