SMC Networks HRR012-A*-20 Series User Manual

HRX-OM-W002-A
Chapter 9 Documents
HRR Series 9.1 Specifications
9-1
Chapter 9 Documents
9.1 Specifications
9.1.1 HRR012/018/024/030-A-20-(DMTUY)
Table 9-1 Specifications [HRR012/018/024/030-A-20-(DMTU)]
Model
HRR012-A
-20-(DMTUY)
HRR018-A
-20-(DMTUY)
HRR024-A
-20-(DMTUY)
HRR030-A
-20-(DMTUY)
Cooling method
Air-Cooled refrigerated type
Refrigerant
R410A(HFC)
Quantity of refrigerant
Kg
0.38
0.38
0.47
0.47
Control method
PID control
Ambient temperature andhumidity and altitude

1
Temperature:5 to 40℃、Humidity:30 to 70%、Altitude: Less than 3000m
Circulating
fluid
system
Circulating fluid

2
Tap water, Ethylene glycol aqueous solution 15%
Operating temperature
range

1
℃
10 to 35
Cooling capacity
(50/60Hz)

3
W
1000/1200
1600/1800
2000/2400
2500/3000
Heating capacity
(50/60Hz)

4
W
450/500
550/700
Temperature stability

5
℃
±0.1
Pump capacity (50/60Hz)

6
L/min
0.13（at 7L/min）/0.18(at 7L/min)
For option –T : 0.42（at 10L/min）/0.4(at 14L/min）
For option –MT : 0.32（at 10L/min）/0.32(at 14L/min）
Rated flow rate
(50/60Hz)

7
L/min
7 / 7 For option –T ,-MT：10/14
Flowdisplay range
L/min
3 to 16
Electric conductivity
display range
µS/cm
2 to 48(For option -DM)
Electric conductivity
setting range
µS/cm
5 to 45(For option -DM)
Particle filter nominal
filtration rating
µm
5
Bypass valve
Installed
Tank capacity
L
Approx. 4
Fluid outlet,fluid return port port size
Rc1/2
Drain port size
Rc1/4,With cap
Leakage protection
Drain pan (With water leakage detector )
Fluid contact part material
Stainless steel,Copper brazing (Heat exchanger)

12
,Brass

17
,SiC,
Aluminum oxide ceramic,Carbon,PP,PE,POM,PA,FKM,EPDM,PVC,
PPS,AS,fluoropolymer

13
,Ion exchange resin

13
Electrical
system
Power supply
1-phase AC200 to 230V 50/60Hz Allowable voltage fluctuation±10%
15
Circuit protector
A
10 (For option -T,-MT：15)
Applicable earth leakage breaker

8
Rated current：10A (For option -T,-MT：15A)
Sensitivity current：30mA
Cable Qty x size(Incuding ground)

16
3 cores ×14AWG(3 cores×2.0m ㎡)
Rated operating current
(50/60Hz)

3
A
3.6/4.0
3.6/4.3
5.2/5.8
5.5/6.2
For option -T,-MT
4.7/6.2
4.7/6.5
6.3/8.0
6.5/8.3
Rated power consumption
(50/60Hz)
18
Kw
(kVA)
0.6/0.8/
(0.7/0.8)
0.7/0.9
(0.7/0.9)
0.9/1.2
(1.1/1.2)
1.0/1.2
(1.1/1.3)
For option -T,-MT
0.9/1.2
(0.9/1.2)
0.9/1.3
(1.0/1.3)
1.2/1.6
(1.3/1.6)
1.3/1.6
(1.3/1.7)
Communication function
Contact input / output, Serial RS-485 / RS-232C
Noise level (50/60Hz)

9
dB
59/60
59/60
61/64
61/64
Dimensions

10
mm
W483xD550xH310
W483xD550xH399
Accessory

19
power supply connector,Maintenance handle for particle filter,
Operation manual,Particle filter element
Weight

11
kg
40
46
1: Use the product in conditions where freezing will not occur. Consult with SMC if using in a season or region where
the ambient temperature will fall below zero.
2: If tap water is used, use water which satisfies the standard of The Japan Refrigeration And Air Conditioning
Industry Association (JRA GL-02-1994/Cooling water system –circulation type - make-up water).
3: (1)Ambient temp: 25℃, (2)Circulating fluid temp.: 20℃, (3)Circulating fluid rated flow, (4)Criculating
fluid : Tap water,(5)Power supply : AC200V, (6)Piping length : Shortest The cooling capacity will be reduced by
300W when option T and MT [High pressure pump] are selected.
