HRX-OM-X010
Chapter 3 Transporting and Installation
3.3 Procedure for Installation HRZ Series
5. Loosen the cap at power cable access (strain relief) and insert the power cable.
[Tips]
See “Table 3-1 Power Cable and Main Breaker (This System)” on page 3-8
for the recommended cable size and crimp contact.
Correct phase rotation is required when attach the power cable to the
breaker terminal.
Do not drop a screw or washer in the electrical unit when attaching the
breaker cover and terminal.
Do not leave it in the unit if dropped in. Potential failure may occur if
the power is turned ON without removing it.
Figure 3-10 Power cable insertion
To Next Page
