SMC Networks HRZ002-WS-F User Manual

HRX-OM-X010
Chapter 2 Name of Each Section
HRZ Series 2.1 Name of Each Section (1)
2-1
2-1
Chapter 2 Name of Each Section
2.1 Name of Each Section (1)
HRZ***-WS-F HRZ***-W1S-F HRZ***-W2S-F
,
Figure 2-1 Name of Each Section (1)
[Tips]
The front casters (2 pcs.) have built-in brakes. The disengagement of the
brakes is required when transporting the system.
Caster w/ brake
Rotates 360°.
Emergency off [EMO] switch
Main breaker
Power cable access
Circulating fluid
fill port
Facility water outlet
Circulating fluid
return
Circulating fluid level gauge
Circulating fluid supply
Drain pan port
Facility water inlet
Ventilating fan (exhaust side)
Operation display panel
Sub tank drain port
Main tank drain port
Ventilating hole
(intake side)
