- 99 -
No.SFOD-OMT0010-B
4. Actual speed of the product will be changed by the workload.
Before selecting a product, check the catalog for the instructions regarding selection and
specifications.
5. Do not apply a load, impact or resistance, in addition to a transferred load during the “Return
to Origin” operation.
When performing return to origin by pushing force, additional force will cause displacement of the
origin position since it is based on detected motor torque.
6. Do not remove the name plate.
7. An operation test should be carried out using a low speed. Start operation using the
predefined speed after confirming there is no problems.
[Grounding]
Warning
1. Provide a good earth connection to the actuator.
2. The earth should be a dedicated earth connection. Class D dedicated grounding should be
used. (Ground resistance 100Ω or less)
3. The earth cable length should be as short as possible.
[Unpacking]
Caution
1. Check that the received product is as ordered.
If a different product is installed, other than that ordered, injury or damage can result.
13.4 Operating environment
Warning
1. Avoid use in the following environments.
a) Locations where a large amount of dust and cutting chips are airborne.
b) Locations where the ambient temperature is outside the range of the temperature
specification (refer to specifications).
c) Locations where the ambient humidity is outside the range of the humidity specification
(refer to specifications).
d) Locations where corrosive gas, flammable gas, seawater, water and steam are present.
e) Locations where strong magnetic or electric fields are generated.
f) Locations where direct vibration or impact is applied to the product.
g) Areas that are dusty, or are exposed to splashes of water and oil drops.
h) Areas exposed to direct sunlight (ultraviolet ray).
i) Environment at an altitude of 1000 meters or higher.
Heat dissipation and withstand voltage will decrease. Contact SMC for details.
2. Do not use in an environment where the product is directly exposed to liquid, such as
cutting oils.
If cutting oils, coolant or oil mist contaminates the product, failure or increased sliding
resistance can result.
3. Install a protective cover when the product is used in an environment directly exposed
to foreign matter such as dust, cutting chips and spatter.
Play or increased sliding resistance can result.
4. Provide a protective cover if the product is used in direct sunlight.
5. Shield the product if there is a heat source nearby.
When there is a heat source surrounding the product, the radiated heat from the heat source
can increase the temperature of the product beyond the operating temperature range.
6. Grease oil can be reduced due to the external environment and operating conditions.
The lubrication performance may deteriorate and shorten the life of the product.
To Next Page
