- 23 -
No.SFOD-OMT0010-B
3.8 Operation test using Test Drive
Select "View(V)" at the top of the main window, and select "Test Drive".
The Test Drive window will be displayed.
It is possible to test the set step data in a specified order.
(1) Test Drive setting
Set the order of the step data number for testing in the test drive list window. The table below
shows details of the items required.
Step number to be executed.
The set line is deleted by entering "-1".
Wait time after the actuator has been operated by the step data, specified by
the step number. Unit is msec.
Setting range is 0 to 32767 msec.
Comments are possible to be entered. (Note that half-width comma "," cannot
be used).
(2) Change to Remote mode
Turn on the Servo, referring to section
3.7 (1) Change to Remote mode.
To Next Page
