SMC Networks JXC73 Series

- 24 -
No.SFOD-OMT0010-B
(3) Return to origin
Confirm that SVRE output is ON, refer to section
3.7 (1) Change to Remote mode
. Then, select
"All axes Return to Origin", and perform the “Return to origin” operation.
(4) Test drive starts
Confirm that SETON output is ON, refer to section
3.7 (2) Return to origin
.
Test drive starts by pressing the "Go" button, based on the test drive list.
Test drive is completed when the correct operation is confirmed. If the operation was not as
expected, then refer to section
3.6 (3) Step data settings
to revise the settings.
Caution
Do not disconnect the USB cable while executing step data.
The actuator will stop.
