- 81 -
No.SFOD-OMT0010-B
10. Accessories
10.1 Power cable for main control
JXC-C1
Cable specification
Item
Specifications
Cable length
1.5m
Electric wire size
Stranded wire --> AWG20 (0.5mm
2
)
O.D. of sheath 1.76 mm
Wire sheath colour
+24V: Brown
24-0V: Blue
10.2 DIN rail mounting bracket
JXC-Z1
Included with the controller
Description
Size
Qty.
Cross recessed
round head screw
M5x8
4 pcs.
M5x14
2 pcs.
(1500)
Cable colour: Blue (0V)
Cable colour: Brown(24V)
