Additional Information
VorTek ProtoCessor Start-up Guide 53
11 Vendor Information – VorTek
11.1 Ultrasonic Modbus RTU Mappings to Modbus and BACnet
Point Name
BACnet Data Type
BACnet Object ID
Modbus Register
Volume Flow
AI
1
30007-30008
Mass Flow
AI
2
30009-30010
Temperature 1
AI
3
30001-30002
Velocity
AI
4
32555-32556
Velocity (ft/sec)
AI
5
30029-30030
Delta Time Filtered (ns)
AI
6
32553-32554
Volume Units
AI
7
32007-32012
Mass Units
AI
8
32001-32006
Temperature Units
AI
9
32025-32030
Velocity Units
AI
10
32073-32078
Length Units
AI
11
32079-32084
Net Volume Flow Totalizer
AI
12
30545-30546
Forward Volume Flow Totalizer
AI
13
30501-30502
Reverse Volume Flow Totalizer
AI
14
30549-30550
Net Mass Flow Totalizer
AI
15
30547-30548
Forward Mass Flow Totalizer
AI
16
30503-30504
Reverse Mass Flow Totalizer
AI
17
30551-30552
Volume Total Units
AI
18
32055-32060
Mass Total Units
AI
19
32061-32066
Low Flow Cutoff
AV
1
43193-43194
Zero
AV
2
45159-45160
Tag
AV
3
48501-48524
Signal Quality
AI
20
32551-32552
Time of Flight
AI
21
32501-32502
Speed of Sound
AI
22
32537-32538
Speed of Sound Ratio
AI
23
32549-32550
Transducer
AI
24
34564
Transducer Mounting
AI
25
34567
Transducer Spacing
AI
26
32557-32558
Pipe Inside Diameter
AI
27
33159-33160
Density
AI
28
30015-30016
Viscosity
AI
29
30013-30014
Reynolds Number
AI
30
30031-30032
Enthalpy 1
AI
31
30017-30018
Enthalpy 2
AI
32
30019-30020
Reset Totalizers
BV
1
9
Clear Alarm History
BV
2
12
Reboot Device
BV
3
8
Set Zero
BV
4
21
Energy Flow
AI
33
30011-30012
Energy Units
AI
34
32013-32018
Temperature 2
AI
35
30003-30004
Delta Temperature
AI
36
30191-30192
Energy Total Units
AI
37
32067-32072
Net Energy Flow Totalizer
AI
38
30543-30544
Forward Energy Flow Totalizer
AI
39
30505-30506
Reverse Energy Flow Totalizer
AI
40
30507-30508
11.2 Actival_Plus Modbus RTU Mappings to Modbus and BACnet
Point Name
BACnet Data Type
BACnet Object ID
Modbus Register
Control Setting Value
AV
1
04096
Actual Valve Position
AI
2
04097
Point Status Energy
BI
3
04105.7
Point Status Return Water Temp
BI
4
04105.8
Point Status Supply Water Temp
BI
5
04105.9
Point Status Valve Outlet Pressure
BI
6
04105.10
Point Status Valve Inlet Pressure
BI
7
04105.11
Point Status Set Flow
BI
8
04105.12
