SMC Networks ProtoCessor FPC-ED2 User Manual

Additional Information
VorTek ProtoCessor Start-up Guide 56
12 Specifications
ProtoCessor FPC-ED2
Electrical Connections
One 3-pin Phoenix connector with RS-485 port (+ / - / gnd)
One Ethernet 10/100 BaseT port
Approvals
CE certified; UL 916 approved; WEEE compliant; EN 60950-1,
EN 50491-3 and CSA C22-2 standards; FCC Class A Part 15;
DNP 3.0 conformance tested; RoHS compliant; CSA 205 approved
BTL Marked
Power Requirements
5VDC
Physical Dimensions
6.9 x 3.0 x 2.0 cm (2.7 x 1.2 x 0.8 in.)
Weight
0.03 kg (0.07 lbs)
Operating
Temperature
-40°C to 75°C (-40°F to167°F)
Surge Suppression
EN61000-4-2 ESD EN61000-4-3 EMC EN61000-4-4 EFT
Humidity
5 - 90% RH (non-condensing)
(Specifications subject to change without notice)
Figure 53: Specifications
Warning: This equipment is compliant with Class A of CISPR 32. In a residential environment, this
equipment may cause radio interference.
12.1.1 Compliance with UL Regulations
For UL compliance, the following instructions must be met when operating the ProtoCessor.
• The units shall be powered by listed LPS or Class 2 power supply suited to the expected operating
temperature range.
• The interconnecting power connector and power cable shall:
o Comply with local electrical code
o Be suited to the expected operating temperature range
o Meet the current and voltage rating for the ProtoCessor
• Furthermore, the interconnecting power cable shall:
o Be of length not exceeding 3.05m (118.3”)
o Be constructed of materials rated VW-1, FT-1 or better
• If the unit is to be installed in an operating environment with a temperature above 65 °C, it should
be installed in a Restricted Access Area requiring a key or a special tool to gain access.
• This device must not be connected to a LAN segment with outdoor wiring.
