VorTek ProtoCessor Start-up Guide 55

11.4 Pro-T_M22_M23 Modbus RTU Mappings to Modbus and BACnet

Point Name

BACnet Data Type

BACnet Object ID

Modbus Register

Serial Number

65100\65101

Totalizer

00525\00526

Totalizer Units

02037\02038

Mass Flow

00009\00010

Volume Flow

00007\00008

Pressure

00005\00006

Temperature

00001\00002

Velocity

00029\00030

Density

00015\00016

Viscosity

00013\00014

Reynolds Number

00031\00032

Vortex Frequency

00025\00026

Gain Char

04532

Vortex Amplitude

00085\00086

Filter Setting

00027\00028

Totalizer #2

00527\00528

Totalizer #2 Units

02043\02044

Temperature #2

00003\00004

Energy Flow

00011\00012

Volume Flow Units

02007\02008

Mass Flow Units

02001\02002

Temperature Units

02025\02026

Pressure Units

02019\02020

Density Units

02031\02032

Energy Flow Units

02013\02014

Alarm #1 State

00001

Alarm #2 State

00002

Alarm #3 State

00003

Table of Contents4
Introduction7
Protocessor Gateway7
Setup for Protocessor8
Record Identification Data8
Configuring Device Communications8
Confirm the Device and Protocessor COM Settings Match8
Set Node-ID for the Device8
Figure 1: Protocessor Part Numbers8
Figure 2: COM Settings8
Interfacing Protocessor to Devices9
Protocessor FPC-ED2 Showing Connection Ports9
Figure 3: Protocessor FPC-ED29
Serial Network: Wiring Field Port to RS-485 Network10
Figure 4: Connection from Protocessor to RS-485 Field Network10
Figure 5: RS-485 EOL & Bias Resistor Switches10
Connect the PC to the Protocessor11
Connecting to the Gateway Via Ethernet11
Changing the Subnet of the Connected PC11
Figure 6: Ethernet Port Location11
Setup Web Server Security12
Login to the Fieldserver12
Figure 7: Web Server Security Window12
Figure 8: Connection Not Private Warning12
Figure 9: Warning Expanded Text13
Figure 10: Fieldserver Login13
Select the Security Mode14
Figure 11: Security Mode Selection Screen14
HTTPS with Own Trusted TLS Certificate15
HTTPS with Default Untrusted Self-Signed TLS Certificate or HTTP with Built-In Payload Encryption15
Figure 12: Security Mode Selection Screen - Certificate & Private Key15
Configure Network Settings16
Navigate to the Network Settings16
Figure 13: Generic Web App Landing Page16
Figure 14: Settings Tabs16
Figure 15: FS-GUI Landing Page16
Change the Protocessor IP Address17
Figure 16: Ethernet Port Network Settings17
Grid User Setup, Registration and Login18
Choose Whether to Integrate the Grid18
Figure 17: Generic Web App Page - First Login18
Figure 18: Grid Fieldserver Manager Opt out Warning Window19
User Setup20
Figure 19: Welcome to SMC Cloud Email20
Figure 20: Setting User Details21
Registration Process22
Figure 21: Grid Registration Message22
Figure 22: Grid Registration - Installer Details23
Figure 23: Grid Registration - Site Details23
Figure 24: Grid Registration - Gateway Details24
Figure 25: Grid Registration - Grid Account24
Figure 26: Device Registered for the Grid25
Login to the Grid26
Figure 27: Grid Login Page26
Figure 28: Grid Landing Page27
Configure the Protocessor28
Navigate to the Protocessor Web Configurator28
Figure 29: Web App Landing Page28
Figure 30: Configure Tab28
Select Field Protocol and Set Configuration Parameters29
Figure 31: Web Configurator Protocol Selector Parameter29
Setting Protocessor Active Profiles30
Figure 32: Web Configurator Showing no Active Profiles30
Verify Device Communications31
Figure 33: Web Configurator Showing Active Profile Additions31
Bacnet: Setting Node_Offset to Assign Specific Device Instances32
Figure 34: Web Configurator Node Offset Field32
Figure 35: Active Profiles32
Troubleshooting33
Lost or Incorrect IP Address33
Figure 36: Ethernet Port Location33
Viewing Diagnostic Information34
Figure 37: Error Messages Screen34
Checking Wiring and Settings35
LED Diagnostics for Communications between Protocessor and Devices36
Figure 38: Diagnostic Leds36
Taking a Fieldserver Diagnostic Capture37
Taking a Capture with Older Firmware38
Figure 39: Ethernet Port Location38
Additional Information40
Update Firmware40
Bacnet: Setting Network_Number for more than One Protocessor on the Subnet40
Figure 40: Web Configurator - Network Number Field40
Internet Browser Software Support41
Certification41
BTL Mark - Bacnet Testing Laboratory41
Change Web Server Security Settings after Initial Setup42
Figure 41: FS-GUI Page42
Change Security Mode43
Figure 42: FS-GUI Security Setup43
Edit the Certificate Loaded Onto the Fieldserver44
Figure 43: FS-GUI Security Setup - Certificate Loaded44
Change User Management Settings45
Figure 44: FS-GUI User Management45
Create Users46
Figure 45: Create User Window46
Edit Users47
Figure 46: Setup Users47
Figure 47: Edit User Window47
Delete Users48
Figure 48: Setup Users48
Figure 49: User Delete Warning48
Change Fieldserver Password49
Figure 50: Fieldserver Password Update Via FS-GUI49
Grid Connection Warning Message50
Figure 51: Grid Connection Problems Message50
System Status Button51
Routing Settings52
Figure 52: Routing Settings52
Vendor Information - Vortek53
Ultrasonic Modbus RTU Mappings to Modbus and Bacnet53
Actival_Plus Modbus RTU Mappings to Modbus and Bacnet53
U42_U43 Modbus RTU Mappings to Modbus and Bacnet54
Pro-T_M22_M23 Modbus RTU Mappings to Modbus and Bacnet55
Specifications56
Compliance with UL Regulations56
Figure 53: Specifications56
Limited 2 Year Warranty57
