Introduction Functional Description
Figure 2-2 ETHOS™ unit front view
1— Y/a (accept) button
2— S button
3— b (Up) button
4— N/x (back) button
5— CompactFlash
®
card slot, under endgrip
6— c (Right) button
7— Power button
8— d (Down) button
9— e (Left) button
Figure 2-3
ETHOS™ unit top view
1— DC power supply input
2— Data cable connector
3— USB port
4— Mini USB port
1
2
3
4
6
7
8
9
5
1
2
3
4

Snap-On ETHOS Specifications

General

Touchscreen	Yes
Display Resolution	1280 x 800
Operating System	Android
Connectivity	Wi-Fi, Bluetooth
Battery Life	8 hours
Compatibility	OBD-II
Software Updates	Regular updates
