Snap-On ETHOS User Manual

5
Introduction Technical Specifications
Figure 2-4 ETHOS™ unit back view
1— Battery cover
2— Locking tabs
2.2 Technical Specifications
Display:
Light Emitting Diode (LED) backlight monochrome screen
320 x 240 resolution
4.7 inch (119.38 mm) diagonal
Batteries:
(6) 1.5V AA
AC adapter:
Input: 100–240V, 47–63 Hz
Output: 15V DC
Dimensions:
Width:
9.05 inches
229.9 mm
Height:
5.70 inches
144.7 mm
Depth:
1.67 inches
42.3 mm
1
2

Snap-On ETHOS Specifications

General

Touchscreen	Yes
Display Resolution	1280 x 800
Operating System	Android
Connectivity	Wi-Fi, Bluetooth
Battery Life	8 hours
Compatibility	OBD-II
Software Updates	Regular updates
